Erica Synths Fusion VCF 3

Erica Synths Fusion VCF 3
The Fusion VCF3 is resonant 24dB/oct lowpass filter of unique design that combines vacuum tubes and vactrols, providing distinct, soft filtering. For more versatility, the independent audio mixer and buffered multiple is incorporated in the module, and, most importantly – a CV recorder that records motion of the potentiometer, so you can design advanced modulation patterns.
 Full analogue design
Vacuum tube and vactrol based filter circuit. Because of vactrol lag,the VCF will not accept audio rate modulation, the maximummodulation frequency is 10HzInput signal mixer with gain 2 for signal overdriveBuffered multiple for splitting audio and CV signalsPotentiometer motion record unit with CV and gate outputsRecorded CV multiplication and division
Technical Specifications:

Filter slope 24dB/oct
Audio Input level 10Vptp
CV input level -5V – 5V
CV Output level 0V – 5V
Panel width 20HP
Module depth 36mm
Power consumption 81mA@ 12V, 76mA@-12V
